MIL-DTL-23053/11C
TABLE II.
Physical properties. 1/
Characteristic
Requirement
Test Procedure and conditions
As supplied:
ID, minimum
Table I
4.6.3
Restricted
No cracks
4.6.6.1.1 175° ± 2°C
shrinkage
(347° ± 4°F)
Voltage withstand
Pass
4.6.6.2
Clarity stability
Pass
4.6.16 175° ± 1°C
(347° ± 2°F), 24 hours
After unrestricted
shrinkage:
ID, maximum
Table I
4.6.3
Wall thickness
Table I
4.6.3
Tensile strength
2,000 (13.8)
4.6.13 ASTM D638, 2
psi (MPa), minimum
inches/minute
Ultimate elongation,
200
4.6.13 ASTM D638, 2
percent, minimum
inches/minute
Dielectric strength,
500(12.7)
4.6.2 ASTM D2671
volts/roil (Kv/mm),
minimum
1017
Volume resistivity,
4.6.2 ASTM D876
Ohm-cm, minimum
Water aborption,
0.01
4.6.2 ASTM D570, 24 hrs
percent, maximum
at 23°C
Low temperature
No cracks
4.6.7.1 -65° ± 1°C
flexibility
(-85° ± 2°F)
Heat resistance,
4.6.9 250° ± 3°C
properties after:
(482° ± 5.4°F),
96 hours
Tensile strength, psi
2000(13.8)
(MPa), minimum
4
