MIL-DTL-23053/5C
TABLE II. Physical properties. 1/
Characteristic
Requirement
Test procedure and condition
As supplied:
ID, minimum
Table I
4.6.3
Heat shock
No cracks, flowing
4.6.8 Classes 1 and 2: 250°
or dripping
± 3°C (482° ± 6°F); Class
3: 225° ± 3°C (437° ± 6°F)
Secant modulus,
25,000 (172.4)
4.6.12.1, 2 percent strain,
psi (MPa), max.
ASTM D882
Concentricity
70% minimum
4.6.3.3
(50% minimum for
over expanded
sizes)
Color stability
Pass
4.6.15 175° ± 2°C
(347° ± 4°F), 24 hours
Clarity stability
Pass
4.6.16 175° ± 2°C
Clear
(347° ± 4°F), 24 hours
Restricted shrinkage
No cracks
4.6.6.1.1 175° ± 2°C
(347° ± 4°F)
Voltage withstand
Pass
4.6.6.2
After unrestricted
shrinkage:
ID, maximum
Table I
4.6.3
Wall thickness
Table I
4.6.3
Tensile strength,
1,500 (10.3)
4.6.13 ASTM D638, 20
psi (MPa), minimum
inches/minute
Ultimate elongation,
200
4.6.13 ASTM D638, 20
percent, minimum
inches/minute
Dielectric strength,
500 (19.7)
4.6.2 ASTM D2671
Volts/roil (Kv/mm),
minimum
4
