MIL-DTL-23053/12C
TABLE II.
Physical properties. 1/ - Continued
Characteristic
Requirement
Test procedure and conditions
Volume resistivityj
1018
Ohms-cm, minimum
4.6.2 ASTM D876
Water absorption,
percent, maximum
0.01
4.6.2 ASTM D570,
para. 6.l
Specific gravity,
maximum
2.20
4.6.2 ASTM D792
Low temperature
flexibility
No cracking
4.6.7.1 -65° ± 2°C
(-85° ± 4°F)
Heat resistance,
properties after:
4.6.9 350° ± 4°C
Tensile strength,
(662° ± 8°F), 96 hours
psi (MPa), minimum
2,500 (17.3)
Ultimate elongation,
percent, minimum
200
Dielectric strength,
volts/roil (Kv/mm),
minimum
800 (31.5)
Flammability
Non-flammable
2/
Corrosion
2/
Non-corrosive
Fluid resistance
2/
No change
Fungus resistance
No growth
2/
1/ Unless otherwise specified, all requirements, conditions and procedures
are for all classes.
2/ Because of their relative inertness, MIL-I-23053/12 sleevings are not
normally subjected to these requirements. However, the acquiring
activity (see 6.2) may, at its option, specify the performance of
any or all of these requirements.
7
