MIL-DTL-23053/16B
TABLE I.
Construction details, inches (mm). 1/
Military
As supplied
After unrestricted shrinkage
part number
ID minimum
ID maximum
Wall thickness, nominal
M23053/16-001-0
.250(6.35)
.035
(.889)
.125(3.18)
M23053/16-002-0
.375(9.53)
.187(4.75)
.040
(1.02)
M23053/16-003-0
.500(12.7)
.250(6.35)
.048
(1.23)
M23053/16-004-0
.750(19.1)
.375(9.53)
.057
(1.45)
M23053/16-005-0
1.000(25.4)
.500(12.7)
.070
(1.78)
M23053/16-006-0
1.500(38.1)
.750(19.1)
.095
(2.41)
M23053/16-007-0
2.000(50.8)
.110
(2.79)
1.000(25.4)
M23053/16-008-0
3.000(76.2)
1.500(38.1)
.125
(3.18)
M23053/16-009-0
4.000(101.6)
2.000(50.8)
.140
(3.56)
1/ Diameter limits for the object to be enclosed shall be as recommended
in technical data.
2/ The color code identified is the standard acquisition color.
Unrestricted shrinkage procedures:
Test method 4.6.5; 175° ± 2±C (347° ± 4°F)
for 10 minutes.
TABLE II. Physical properties. 1/
Characteristic
Test Procdeure and conditions
Requirement
As supplied:
ID, minimum
4.6.3
Table I
Low temperature
No cracks
4.6.7.1 -65° ± 2°C
flexibility
(-85° ± 4°F)
Heat shock
No cracks,
4.6.8 200° ± 2°C
flowing or
(392° ± 4°F)
dripping
Restricted shrinkage
No cracks
4.6.6.1.1 150° ± 2°C
(302° ± 4°F)
Voltage withstand
4.6.6.2
Pass
After unrestricted
shrinkage:
ID, maximum
Table I
4.6.3
2
