INCH-POUND
MIL-DTL-23053/13B
17 June 1996
SUPERSEDING
MIL-I-23053/13A
01 May 1986
DETAIL SPECIFICATION SHEET
INSULATION SLEEVING, ELECTRICAL, HEAT SHRINKABLE,
FLUOROELASTOMER, FLEXIBLE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the sleeving described herein shall consist
of this specification sheet and the issue of the following specification
listed in that issue of the Department of Defense Index of Specifications
and Standards (DODISS) specified in the solicitation: MIL-DTL-23053.
REQUIREMENTS:
Polymer type:
The base elastomer used in formulating this sleeving shall be
fluoroelastomer.
Continuous operating temperature range:
-40°C (-40°F) to +200°C (+392°F).
Color: The heat shrinkable sleeving shall be furnished in the color specified
by the acquisition activity (see 6.2b); however, black shall be considered
standard. Colors shall conform to the requirements of Class II of MIL-STD-104.
Longitudinal change:
± 20 percent.
Military part number: The Military part number shall consist of the basic
number of this specification sheet and dash numbers as follows:
M23053/13 - X XX - X
Color code designator (see 1.2.1)
Size identifier (see table I)
Class (When no classes are specified in the
specification sheet, the numeric "0"is
used)
Specification sheet
AMSC N/A
FSC 5970
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
1 of 5
