MIL-DTL-23053/13B
Example: Black, 0.500 inch (12.7 mm) as supplied ID sleeving shall be
identified as M23053/13-O04-0.
TABLE I.
Construction details, inches (mm). 1/
Military
After unrestricted shrinkage
As supplied
part number 3/
ID minimum
Wall thickness 2/
ID maximum
M23053/13-001-*
.187(4.7)
.035
±
.007(.9 ± .18)
.094(2.4)
M23053/13-O02-*
.035
±
.007(.9 ± .18)
.250(6.4)
.125(3.2)
M23053/13-O03-*
.035
±
.007(.9 ± .18)
.375(9.5)
.187(4.7)
M23053/13-O04-*
.500(12.7)
.035
±
.007(.9 ± .18)
.250(6.4)
M23053/13-O05-*
.625(15.9)
.042
±
.008(1.1 ± .20)
.312(7.9)
M23053/13-O06-*
.042
±
.008(1.1 ± .20)
.750(19.1)
.375(9.5)
M23053/13-O07-*
.049
±
.011(1.2 ± .28)
.875(22.2)
.437(11.1)
M23053/13-O08-*
.049
±
.011(1.2 ± .28)
1.000(25.4)
.500(12.7)
M23053/13-O09-*
.055
±
.015(1.4 ± .38)
1.250(31.8)
.625(15.9)
M23053/13-010-*
.055
±
.015(l.4 ± .38)
1.500(38.1)
.750(19.1)
M23053/13-011-*
.065
±
.017(1.7 ± .43)
2.000(56.8)
1.000(25.4)
M23053/13-012-*
.063(1.6)
.065
±
.017(l.7 ± .43)
.125(3.21
1/ Diameter limits for object to be enclosed shall be as specified in
technical data.
2/ Wall thickness values are less when shrinkage is restricted.
3/ The asterisk in the part number shall be replaced by color code designations
(see 1.2.1). Black is the standard color.
Unrestricted shrinkage:
Test method 4.6.5; 200° ± 5°C (392° ± 9°F) for 10
minutes maximum.
Table II.
Physical properties.
Characteristic
Requirement
Test procedure and conditions
As supplied:
ID, minimum
Table I
4.6.3
Cold impact
No cracking
4.6.7.2 -40° ± 1°
(-40° ± 2°)
2
,
.
.
