INCH-POUND
MIL-DTL-23053/14B
17 June 1996
SUPERSEDING
MIL-I-23053/14A
01 May 1986
DETAIL SPECIFICATION SHEET
INSULATION SLEEVING, ELECTRICAL, HEAT SHRINKABLE,
ETHYLENE-TETRAFLUOROETHYLENE FLUOROPOLYMER, SEMI-RIGID
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the sleeving described herein shall consist
of this specification sheet and the issue of the following specification
listed in that issue of the Department of Defense Index of Specifications
and Standards (DODISS) specified in the solicitation: MIL-DTL-23053.
REQUIREMENTS:
Polymer type:
The base polymer used in formulating this sleeving shall be
ethylene-tetrafluorethylene fluoropolymer.
Continuous operating temperature range:
-100°C (-148°F) to 150°C (302°F).
Color: The sleeving shall be furnished in clear (translucent white to
transparent blue), the as manufactured color.
± 10 percent
Longitudinal change:
Military part number: The Military part number shall consist of the basic
number of this specification sheet and dash numbers as follows:
M23053/14 - X XX - X
Color code designator (see 1.2.1)
Size identifier (see table I)
Class (When no classes are specified in the
specification sheet, the numeric "0"
is used)
Specification sheet
AMSC N/A
FSC 5970
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
1 of 4
