INCH-POUND
MIL-DTL-23053/8C
17 June 1996
SUPERSEDING
MIL-I-23053/8B
01 May 1986
DETAIL SPECIFICATION SHEET
INSULATION SLEEVING, ELECTRICAL, HEAT SHRINKABLE,
POLYVINYLIDENE FLUORIDE, SEMI-RIGID, CROSSLINKED
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the sleeving described herein shall consist
of this specification sheet and the issue of the following specification
listed in that issue of the Department of Defense Index of Specifications
and Standards (DODISS) specified in the solicitation: MIL-DTL-23053.
REQUIREMENTS:
Polymer type:
The base polymer used in formulating this sleeving shall be
polyvinylidene fluoride homopolymer. (see 23053/18 for co- and ter-polymers of
this material.
Continuous operating temperature range: -55°C (-67°F) to +175°C (+347°F).
Color: The heat shrinkable sleeving shall be furnished transparent to
translucent light tan (clear). Colors are available and shall conform to
requirements of Class 1, MIL-STD-104.
Longitudinal change: ± 10 percent
Military part number: The Military part number shall consist of the basic
number of this specification sheet and dash numbers as follows:
M23053/8 - X XX - X
Color code designator (see 1.2.1)
Size identifier (see table I)
Class (When no classes are specified in the
specification sheet, the numeric "O"
is used)
Specification sheet
FSC 5970
AMSC N/A
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
1 of 5
