MIL-DTL-23053/7C
Wall thickness tolerance
(as supplied)
Wall
Tolerance
inch
inch
(mm)
(mm)
.0015
(.038)
(.0127)
*
.0005
.0016 to .003 (.041 to .076)
*
.0008
(.0203)
.0031 to .005 (.079 to .127)
(.0254)
*
.0010
.0051 to .010 (.130 to .254)
*
.0015
(.0381)
4/ The asterisk in the part number shall be replaced by color code
designations (see 1.2.2).
Unrestricted shrinkage:
Test method 4.6.2.2; 160° ± 2°C (320° ± 4°F)
for 5 minutes.
TABLE II.
Physical properties.
Characteristic
Test procedure and conditions
Requirement
As supplied:
ID, minimum
Table I
4.6.3
Restricted shrinkage
No cracks
4.6.6.1.1 160° ± 2°C
(320° ± 4°F)
Voltage withstand
Pass
4.6.6.2
Color stability,
Pass
4.6.15 150° ± 2°C
Class 2
(302° ± 4°F), 48 hours
Clarity stability,
Pass
4.6.16 150° ± 2°C
clear sleeving
(302° ± 4°F), 24 hours
Heat shock
4.6.8 180° ± 2°C
No cracks,
flowing or
(356° ± 4°F)
dripping
After unrestricted
shrinkage:
ID, maximum
Table I
4.6.3
Table I
4.6.3
Wall thickness
4
